EXA Embedded Technology
EXA Embedded Technology consists of arrays of in-house color cameras coupled with source of lights at different spectrum. It allows a comprehensive identification of contamination, foreign fibers and material defects in textiles.
These technologies face the critical and harsh conditions of preparation and processing lines. Low maintenance costs, easy friendly software and full automation complete the design.
Identification of contamination
This is a paragraph where you can add any information you want to share with website visitors. Click here to edit the text, change the font and make it your own.
UV light spectrum
Identification of optically brightened contamination.
Red light spectrum
Identification of glossy contamination surface.
White light spectra
Identification color and light color contamination.
Removal of contamination
Loptex EXA separates contamination in a continuous fibers flow. It does not interfere with the production of the line. It guarantees efficient removal of contaminants.
Array of solenoid valves
The array of solenoid valves enables on-time separation of contamination. Only one valve is activated for the targeted expulsion of the contaminant.
Intelligent software
Intelligent software synchronizes the detection systems with the solenoid valves through dedicated hardware. Each valve contains three nozzles.
Minimum loss of non-faulty material
The filtering of cotton tuft shadows and the measuring of their speed allow significant reduction of false rejections. The loss of good fibers is then reduced to its minimum.
Classification
Loptex EXA captures the contamination images and classifies them according to color and size.
Spinning
Easy Link EXA
The Easy Link EXA upwards fibers flow is a space-saving solution to existing and new compact blow room lines. It is recommended to process high contaminated cottons. It monitors a production up to 1000 Kg/h. On demand, it monitors a production up to 1200 Kg/h.
Nonwovens
Easy Link EXA - NW
The Easy Link EXA-NW upwards fibers flow is a space-saving solution to existing and to new compact nonwovens blow room lines. It monitors a production up to 1000 Kg/h. On demand, it monitors productions up to 1200/2000 Kg/h.
Flakes and Fibers Recycling
Easy Link EXA
The Easy Link EXA upwards fibers flow is a space-saving solution to existing and new tearing lines. It is recommended to process post-industrial and post-consumer flakes and recycled fibers. It monitors a production up to 1000 Kg/h. On demand, it monitors a production up to 1200/2000 Kg/h.
Nonwoven & Technical Textiles. EXA Webs
EXA Web identifies the remaining of contamination and defects on finished webs and provides their mapping distribution on the rolls. It is a complementary solution to the Easy Link EXA NW system installed at the beginning of the process before cards. This combined solution offers a total control of contamination and defects in Nonwovens and Technical Textiles.
EXA Versatility and Compliance
EXA modular concept leads to tailor – made solutions on customer demand. EXA combines multiple technologies which identify and analyze contamination of natural, artificial, synthetic fibers and material defects. EXA monitors different fiber mixing and colors. EXA identification performance, through arrays of embedded color cameras coupled with a combination of source of lights, features:
-Direct viewing with high resolution and accuracy.
-Elimination of optical side distortion.
-Completely sealed optical path.
-Constant sensitivity level on whole inspection field.
