Recycling
Loptex offers valuable solutions to the sorting problem of flakes and fibers in the recycling industry. The target is the transformation of industrial pre-consumer waste and industrial post-consumer waste into sustainable and suitable raw material for further processing. Loptex introduces into the new circular value chain and contributes to filling the gap with sorting capacity.
Contamination may be:
Black spots
Piece of fabrics
Color flakes
Foreign fibers
Color bunch of fibers
Color thread
Color flakes
Color bunch of fibers
Color thread
Foreign fibers
EASY LINK EXA
The Easy Link EXA offers a space-saving saving solution to existing and new blow room lines.
Features
Option
Upward fibres flow
Perfect fitting on existing fibre stream
Modular concept
Minimal loss of processing material
Automation
Remote control
Link to EXA Data
Techical specification
Max production:
1000 Kg/h (1200/2000 Kg/h on demand)
Power supply:
400 VAC ± 10% 50Hz.
Installed power:
1 kW (EXA system)
1 kW (Waste extraction system)
Air consumption:
0,6/1,2 NL (per contamination removal)
Compressed air supply:
approx. 6-8 bars
Dimensions:
Height 3270 mm
Width 2070 mm
Depth 750 mm
Loptex reserves the right to change dimensions and technical specifications. Copyright reserved.
EXA Data
EXA Data, through an external PC, collects and files statistical and historical data from Sorter units.
It provides key information on machines status and on processing materials.
