Nonwovens - Hygiene and Medical
Loptex supplies sustainable and suitable solutions for the significant reduction of contamination on carded fibers. Modular concepts and embedded technologies successfully match high throughput and high air volume in preparation lines. The final products are made for hygiene and medical purposes. They have to guarantee purity, delicacy, and comfort to the human skin.
Contamination may be:
Packaging material
Colour polypropylene
Yellow fibres
Black spots
Grease deposit
Black fibres
Wood
EASY LINK EXA
The Easy Link EXA offers a space-saving saving solution to existing and new blow room lines.
Features
Option
Upward fibres flow
Perfect fitting on existing fibre stream
Modular concept
Minimal loss of non-faulty material
Automation
Remote control
Link to EXA Class (Data Acquisition and Classification System)
Techical specification
Max production:
1000 Kg/h (1200/2000 Kg/h on demand)
Power supply:
400 VAC ± 10% 50Hz.
Installed power:
1 kW (EXA system)
1 kW (Waste extraction system)
Air consumption:
0,6/1,2 NL (per contamination removal)
Compressed air supply:
approx. 6-8 bars
Dimensions:
Height 3270 mm
Width 2070 mm
Depth 750 mm
Loptex reserves the right to change dimensions and technical specifications. Copyright reserved.
